Description |
|
GreenFloors floor tile for commercial and residential
applications. |
|
|
Size |
12" x 12" and 12" x 24" x 3/16" (4.8 mm). Other sizes available by
special order. |
|
Density |
550 kg/m 3 (34 lbs/ft3) |
|
Thermal Insulation |
ISO 8301 |
|
0.06 W/m ° k |
|
Acoustical Ratings |
over 8" concrete with suspended ceiling |
|
STC = 58 (in accordance with ASTM E413-87) |
|
I IC = 73 (in accordance with ASTM E989-89) |
|
Flammability |
ASTM E 648 = Class 2 Pre-finished - Class 1 Unfinished |
|
Smoke Desity |
Specific Optical Density ASTM E 662 (NFPA 258) |
|
Flaming: -148 Non Flaming: -272 |
|
Compression Recovery |
ISO 9727 |
|
With loading of 38.5 lbs/in2 |
|
|
Residual: 1.5% after 1 hour |
|
|
Breaking tension on traction: no less than 11 lbs/in2 |
|
Thermal Resistance |
ASTM C 518 |
|
Thermal conductivity (k): -0.3490 |
|
Thermal resistance (r): -0.49 |
|
Thermal resistance per inch: -2.87 |
|
Disintegration |
Does not disintegrate in water after boiling for 3 hours. |
|
Dimensional Tolerance |
Length & Width: +/- 0.3 mm |
|
Thickness: +/- 0.2 mm |
|
Squaring |
No greater than 0.2 mm |
|
Finish |
Sanded unfinished or factory finished with 2 coats of UV-curable oil |
|
Abrasion Resistance |
ASTM D 3884 |
|
Abrasion wheels H-18 with 1000 gram |
|
400 wear cycles |
|
Water Vapor Transmision |
-0.128 grains/h ft2 |
|
Permeance |
ASTM E 96 |
|
-0.183 perms |
|
Packaging |
88 sq ft per carton. |
